Jichai Natural Gas Genset

Jichai Gas Genset for Natural Gas and Biogas

Description:

The Jichai Gas Genset for Natural Gas and Biogas is designed for gas-based power generation projects using natural gas or biogas fuel sources. It provides a high-power generator set option for industrial power projects, mining sites, farms, gas resource projects, standby power, and project site power supply. This Jichai gas genset series includes both Jichai natural gas genset and Jichai biogas genset model options. According to the provided parameter tables, the natural gas models cover 500kW / 625kVA to 4000kW / 5000kVA prime power, while the biogas models cover 500kW / 625kVA to 1600kW / 2000kVA prime power. The series includes multiple Jichai gas engine models across 190 series, 200 series, and 26/32 engine platforms. With 12-cylinder, 16-cylinder, and 20-cylinder configurations, this gas engine genset range gives buyers flexible model choices for different project capacities, fuel conditions, and installation requirements.

Key Features at a glance:

Fuel Versions :

Natural Gas / Biogas
Natural Gas Power :

500–4000kW
Biogas Power :

500–1600kW
Engine Range :

12 / 16 / 20 Cylinders

Get Latest Price

Download PDF Catalog

Detailed Technical Specifications

Product Series	Genset Model	Prime Power KW/KVA	Engine Model	No. of Cylinder	Displacement L	Overall Size mm	Gross Weight kg
Jichai Natural Gas Genset Parameters	SJ700NFK/S	500/625	G12V190ZLT-2	12	71.5	6195×2330×2776	13800
	SJ700NFK/S	500/625	12V190ZDT-2	12	71.5	4566×2040×2780	11800
	SJ1000NFK/S	750/937.5	C12V190ZLT-2	12	78.3	4770×2040×2250	13000
	SJ1500NFK/S	1100/1375	H16V190ZLT-2	16	97.53	5998×2180×2540	19800
	SJ1650NFK/S	1200/1500	H16V190ZLT2-2	16	97.53	7757×2585×2864	23000
	SJ1650NFK/S	1200/1500	L12V200ZLT-2	12	96.1	6000×2300×2800	17000
	SJ2100NFK/S	1500/1875	L16V190ZLT-2	16	115.7	8100×2300×2800	26700
	SJ2200NFK/S	1600/2000	L16V200ZLT-2	16	127.3	8100×2300×2800	26700
	SJ2750NFK/S	2000/2500	L20V190ZLT-2	20	144.6	7500×2300×2800	30000
	SJ3000NFK/S	2200/2750	L20V200ZLT-2	20	160.2	7900×2300×2800	20600
	SJ4125NFK/S	3000/3750	12V 26/32	12	204	8330×2930×3638	48000
	SJ5500NFK/S	4000/5000	16V 26/32	16	272	9435×2930×4175	70000
Jichai Biogas Genset Parameters	SJ700BFK/S	500/625	G12V190ZLDZ2-2	12	71.5	5120×2040×2776	13800
	SJ825BFK/S	600/750	C12V190ZLZ-2	12	78.3	4770×2040×2249	11800
	SJ1375BFK/S	1000/1250	H16V190ZL-2	16	97.53	6200×2540×2180	21000
	SJ1500BFK/S	1100/1375	H12V200ZL-2	12	96.1	6000×2300×2800	17000
	SJ1925BFK/S	1400/1750	L16V190ZL-2	16	115.7	8100×2300×2800	26700
	SJ2200BFK/S	1600/2000	L20V190ZL-2	20	144.6	7500×2300×2800	29000

Premium Components for Maximum Reliability

12 / 16 / 20-Cylinder Configuration

The provided models include 12-cylinder, 16-cylinder, and 20-cylinder configurations.

This cylinder range supports different power levels and gives buyers a clearer reference when comparing gas engine genset models. Final model selection should be based on required kW/kVA, fuel conditions, operating environment, and project configuration.
290° Rotating Fan-Shaped Unloading

The tank can be tilted forward for unloading and can rotate 290° for fan-shaped discharge.

This unloading structure gives the operator more flexibility when working around pouring points, road edges, foundations, and narrow construction areas. It helps improve concrete placement convenience without relying only on a fixed unloading direction.
Wide Natural Gas Power Range

The provided table covers natural gas genset models from SJ700NFK/S to SJ5500NFK/S.

The confirmed prime power range is 500kW / 625kVA to 4000kW / 5000kVA. This makes the series suitable for buyers who need medium to high-power gas based genset options for industrial power, mining power, gas resource projects, farms, and project site power supply.
Premium Components for Maximum Reliability

The Jichai natural gas genset is built around high-power gas engine platforms, large-displacement engine options, and a wide model range for gas-based power generation projects. The provided data focuses on model selection, prime power, engine model, cylinder number, displacement, overall size, and gross weight.
